Seibu's oil type wire EDMs cut in a petroleum dielectric rather than deionized water. Oil removes the electrolytic corrosion that water can leave on carbide and hardened steel, which is what makes these machines the choice for fine dies, punches, and carbide tooling.
Specifications for the Seibu M25LP are listed below in imperial and metric, both as published by Seibu America. It runs Seibu's Smart NC control with 5 controlled axes, 4 of them simultaneous, and a 0.01 µm least input increment. Seibu machines are sold and supported in Southern California by MASCO.
Specifications
| Max workpiece dimensions | 10.63 × 10.63 × 3.94 in270 × 270 × 100 mm |
|---|---|
| Max workpiece weight | 330.69 lb150 kg |
| X / Y / Z travels | 9.84 × 9.84 × 7.87 in250 × 250 × 200 mm |
|---|---|
| U / V axis travel | ±1.38 × ±1.38 in±35 × ±35 mm |
| Dielectric | Oil |
|---|---|
| Wire diameter | 0.002 to 0.008 in (0.008 in standard)0.05 to 0.20 mm (0.20 mm standard) |
| Max taper angle | ±10° / 3.94 in±10° / 100 mm |
| Pitch accuracy | ±1 µm±1 µm |
| Control | Smart NC |
|---|---|
| Number of axes | 5 (4 simultaneous) |
| Least input increment | 0.01 µm0.01 µm |
| Machine weight | 6,834.33 lb3,100 kg |
|---|---|
| Machine footprint | 5.81 × 6.69 × 6.62 ft1,770 × 2,040 × 2,018 mm |
Specifications are provided by the manufacturer, are subject to change, and do not constitute a warranty. Published pricing excludes tax, freight, installation, and tooling unless stated.
