Seibu's ultra precision wire EDMs hold ±1 µm pitch accuracy and take wire down to 0.002 in (0.05 mm). They share the frames of the high precision machines and add the accuracy and finish control needed for die and mold work that would otherwise go to jig grinding.
Specifications for the Seibu MM35UP are listed below in imperial and metric, both as published by Seibu America. It runs Seibu's Smart NC control with 5 controlled axes, 4 of them simultaneous, and a 0.01 µm least input increment. Seibu machines are sold and supported in Southern California by MASCO.
Specifications
| Max workpiece dimensions | 27.56 × 24.80 × 8.66 in700 × 630 × 220 mm |
|---|---|
| Max workpiece weight | 771.62 lb350 kg |
| X / Y / Z travels | 13.78 × 11.81 × 9.06 in350 × 300 × 230 mm |
|---|---|
| U / V axis travel | ±2.36 × ±2.36 in±60 × ±60 mm |
| Dielectric | Deionized water |
|---|---|
| Wire diameter | 0.002 to 0.012 in (0.010 in standard)0.05 to 0.30 mm (0.25 mm standard) |
| Max taper angle | ±10° / 8.66 in work thickness (±45° / 1.57 in optional)±10° / 220 mm work thickness (±45° / 40 mm optional) |
| Pitch accuracy | ±1 µm±1 µm |
| Control | Smart NC |
|---|---|
| Number of axes | 5 (4 simultaneous) |
| Least input increment | 0.01 µm0.01 µm |
| Machine footprint | 5.38 × 6.76 × 6.41 ft1,640 × 2,060 × 1,955 mm |
|---|
Specifications are provided by the manufacturer, are subject to change, and do not constitute a warranty. Published pricing excludes tax, freight, installation, and tooling unless stated.
