The Gen Turn C24-G is a compact CNC turning center with a built-in 5C collet chuck and a built-in 2-axis or 3-axis gantry loader for unattended production, aimed at fasteners and similar high volume small parts. An 8-station high speed turret, a Fanuc control, and optional bowl feeders round out the package.
Specifications for the Gen Turn C24-G are listed below in imperial and metric, as published on expandmachinery.com. Expand Machinery is headquartered in Chatsworth, California; Gen Turn machines are sold and supported in Southern California by MASCO.
Specifications
| Bar capacity | 1 in25 mm |
|---|---|
| Chuck size | 5C collet, built in |
| Swing over bed | 10 in250 mm |
| Tool capacity | 8 stations |
| Turret | 8-station hydraulic octagonal turret (gang tool version available) |
| X / Y / Z travels | 3.937 × 9.448 in (X × Z)100 × 240 mm |
|---|
| Spindle speed | 6,000 rpm |
|---|---|
| Spindle bore / draw tube | 1.37 in35 mm |
| Spindle horsepower | 7 hp (30-minute rated; 5 hp continuous, 5 / 3.7 kW) |
| Rapid traverse | 468 ipm12 m/min |
|---|
| Control | Fanuc |
|---|---|
| Number of axes | 2 |
| Machine weight | 3,087 lbs1,400 kg |
|---|---|
| Machine footprint | 55 × 40 × 64 in (W × D × H)1,390 × 1,000 × 1,625 mm |
Specifications are provided by the manufacturer, are subject to change, and do not constitute a warranty. Published pricing excludes tax, freight, installation, and tooling unless stated.
