The Gen Turn CW series puts two 12-station BMT-44 live tool turrets against twin built-in spindles, each turret with a full Y axis for milling off centerline. Front and back work run at the same time and parts come off the sub spindle finished. A Marposs tool probe on each turret speeds setup, and a parts catcher with conveyor and dual high pressure coolant pumps are standard.
Specifications for the Gen Turn CW42-MY are listed below in imperial and metric, as published on expandmachinery.com. Expand Machinery is headquartered in Chatsworth, California; Gen Turn machines are sold and supported in Southern California by MASCO.
Specifications
| Bar capacity | 1 5/8 in (1.654 in)42 mm |
|---|---|
| Chuck size | 6 in Kitagawa, main and sub |
| Swing over bed | 14.76 in375 mm |
| Tool capacity | 12 stations (per turret, two turrets) |
| Turret | 12-station BMT-44 driven tool turret on each spindle |
| X / Y / Z travels | 6.693 × ±1.181 × 12.598 in (X × Y × Z, both turrets)170 × ±30 × 320 mm |
|---|
| Spindle speed | 6,000 rpm (built-in motors, main and sub) |
|---|---|
| Spindle bore / draw tube | 1.98 in50.5 mm |
| Spindle horsepower | 10 hp (7.5 kW 30-minute rated, each spindle) |
| Rapid traverse | 787 ipm20 m/min |
|---|
| Number of axes | 8 |
|---|
| Machine weight | 10,584 lbs4,800 kg |
|---|---|
| Machine footprint | 113 × 93 × 65 in (W × H × D)2.6 × 2.02 × 1.63 m |
Specifications are provided by the manufacturer, are subject to change, and do not constitute a warranty. Published pricing excludes tax, freight, installation, and tooling unless stated.
